BetaFPV ExpressLRS review: High Performance drone Radio Link

BetaFPV ELRS review

Starting with July 2021, BetaFPV introduced a new product line based on LoRa powered ExpressLRS radio communication. Their offer ranges from radio receivers and transmitters to flight controllers. You can opt from 2.4GHz, 915 MHZ, or 868 MHz systems according to your needs and RF local regulations. While 900MHz systems allow longer-range and better penetration (for Bando – flying through buildings), the 2.4GHz frequency is more appropriate for racing and freestyling due to the faster response rate and lower latency. Also, low-frequency devices can have longer talk times and require less power than high-frequency devices. If size matters, 2.4GHz requires smaller antennas than 900Mhz.

ExpressLRS (ELRS) is an open-source RC link for various applications, including drone communications. ELRS supports a wide range of hardware platforms and 900 MHz and 2.4 GHz frequency options. ExpressLRS uses LoRa modulation and reduced packet size in order to achieve the best results in terms of class range and latency, compared to current commercial offerings. LoRa is not a new technology, the concept was born in 2015 to provide long-range communication for low-power IoT (Internet of things) devices/sensors.

ELRS aims to achieve the best possible radio link performance for both latency and range. It supports telemetry as an optional feature (with BetaFlight LUA script). What’s more important for drone users is that the ExpressLRS ecosystem claims to be more cost-effective than TBS Crossfire and Frsky R9M.

BetaFPV ELRS lineup

BetaFPV ExpressLRS products review

Disclosure: I received these ExpressLRS electronics as part of a product review collaboration with BetaFPV. Technical specs and quality may vary according to the manufacturer’s reliability, so I cannot guarantee that you will get identical products, as seen in my article.

BetaFPV sent me an ELRS Nano TX unit, an additional T-type Moxon antenna, two Nano RX modules, and an F4 AIO flight controller with a built-in ExpressLRS radio receiver. All for 2.4GHz band.

ELRS Nano TX

1. BetaFPV ExpressLRS Nano TX

I will start with the Nano TX module, which is an external transmitter module that can be attached to the back of your existing transmitter. According to BetaFPV, their module is compatible with Frsky Taranis X-Lite, Taranis X9D Lite, T-Lite, and TBS Tango 2 bays. Personally, I will test it with an OpenTX enabled Jumper T-Lite remote controller. The module has two versions: 915MHz/868MHz and 2.4GHz. All variants can be ordered for $39.99.

ExpressLRS uses the popular Crossfire serial protocol (aka CRSF protocol) to communicate between the radio transmitter and the Nano TX module.

ExpressLRS Nano TX with Jumper T-Lite

The BetaFPV ExpressLRS Nano TX module roughly measures 40x50x100mm and weighs 77grams without the antenna. It comes with two types of antennas, a rubber ducky and a Moxon one (aka T-type). In addition to the heating, there is a status RGB LED and Bind/TX power button on the front panel. The transmission power can be toggled between 100mW (blue), 250mW (purple), and 500mW (red).

BetaFPV provides an online instruction manual that explains the basic configurations of the Nano TX. Note: Never power on the module without an antenna connected!

BetaFPV Nano TX pinout
ELRS Nano TX pinout

ExpressLRS Nano TX specifications

  • Packet refresh rate:
    • 25Hz/50Hz/100Hz/200Hz (915MHz/868MHz)
    • 25Hz/50Hz/150Hz/250Hz/500Hz (2.4GHz)
  • RF output power: 100mW/250mW/500mW
  • Frequency bands
    • Nano RF Module 2.4G version: 2.4GHz ISM
    • Nano RF Module 915MHz/868MHz version: 915MHz FCC/868MHz EU
  • Input voltage: 5V~12V
  • USB port: Type-C

ExpressLRS Nano RX

2. BetaFPV ExpressLRS Nano RX

BetaFPV ELRS Nano RX radio receiver measures just 12x19mm and weighs less than 1 gram. It is built around the ESP8285, a very popular coin-sized SoC (System on Chip). The Nano RX has an onboard status LED, WIFI connectivity, and a firmware upgrade button. The included T-type antenna connects to the board via an IPXE MHF socket. The bag includes connection wires and a 4pin header if you prefer using plugs instead of soldering. BetaFPV also provides two shrink tubes in the bag for short circuit protection.

Nano RX Pavo30 drone

While FrSky radio receivers use only one wire to communicate with the flight controller, the BetaFPV Nano RX uses two: RX and TX. The module requires a 5V input voltage.

The Nano RX frequency needs to be matched with the Nanot TX module. You can opt from 2.4GHz, 915MHz, and 866MHz. All versions are available for $19.99 at BetaFPV.

Nano RX pinout
ELRS Nano RX pinout

ExpressLRS Nano RX specifications

  • Frequency bands:
    • Nano receiver 2.4G version: 2.4GHz ISM
    • Nano receiver 915MHz/868MHz version: 915MHz FCC/868MHz EU
  • Antenna connector: IPEX MHF
  • Telemetry power: 20dbm
  • Size: 12x19mm
  • Weight: 0.7g (receiver only)

3. BetaFPV Moxon antenna for ExpressLRS

The Moxon antenna can be purchased in a package of two for $14.99 or in a bundle with the Nano TX module. Like the other parts of the BetaFPV ExpressLRS ecosystem, it is available in 3 RF versions (2.4GHz, 915MHz, and 866MHz). It comes packed with a small extension cable (SMA to MMCX), this way can be used with TX and RX modules.

Moxon Antenna

915MHz and 866Mhz versions are visibly larger than the 2.4GHz. The T-shape design provides higher directional gain compared to rod antennas.

BetaFPV Moxon antenna 3D radiation pattern
3D radiation pattern

BETAFPV Moxon Antenna specifications

  • Coaxial cable length: 49mm(2.4G)/72mm(915M/868M)
  • Connector: SMA Male
  • Gain:
    • 5.6dBi(2.4G)
    • 5.7dBi(915M)
    • 5.7dBi(868M)
  • VSWR:
    • <2.0(2.4G)
    • <1.5(915M)
    • <1.5(868M)
  • Suggested for: 2.4G/915MHz/868MHz TX and RX modules

ExpressLRS F4 AIO flight controller

4. BetaFPV F4 AIO flight controller with built-in ELRS radio receiver

The BetaFPV F4 AIO flight controller with integrated 2.4GHz ELRS radio receiver can be purchased for $44.99 -this price includes a 2.4GHz dipole T antenna, BT2.0 battery connector, and mounting accessories (Anti-vibration rubber dampers and screws). The BetaFPV HX115 LR Toothpick style FPV drone comes with this ELRS FC installed and pre-configured.

ELRS F4 AIO FC for Whoop and Toothpick drones

With a 29x29mm mounting pattern, it can be installed on small-size Whoop and Toothpick style drones. The flight controller can be powered with 1S batteries (450mAh 30C recommended) and it has an integrated 12A 4in1 ESC. It has a USB Type-C port for firmware upgrade and configuration. The board accepts an external buzzer and RGB LED.

BetaFPV F4 AIO ELRS FC pinout
Flight controller pinout (wiring diagram)

BetaFPV ExpressLRS F4 AIO FC specifications

  • CPU: STM32F411CEU6 (100MHZ )
  • Six-Axis: MPU6000 (SPI connection)
  • Firmware version: betaflight_4.2.0_STM32F411
  • Built-in ELRS 2.4GHz radio receiver
  • Integrated 12A ESC
    • 12A continuous and peak 25A current
    • ESC firmware: Z_H_30_REV16_7.HEX
    • Signal support: D-shot150, D- shot300, D-shot600, Oneshot125, Multishot, PWM
  • Built-in BetaFlight OSD (STM32 controls OSD chip over SPI in DMA mode)
  • USB Port: Type-C firmware/configuration port
  • Mounting Hole Size: 29mm x 29mm (suitable for whoop pattern mounting hole)
  • 1S LIPO battery compatible (BT2.0 connector);
  • Weight: 4.74 grams.

BetaFPV ExpressLRS video reviews and tutorials

REVIEW OVERVIEW
Price/value ratio
Features/Design
Range
Senior editor and co-founder of FirstQuadcopter.com. Everything started about 4 years ago when I purchased my first drone. I still own that Syma X5C . Since then I have had the luck to review and test more than 100 drones.
betafpv-expresslrs-reviewExpressLRS has a rapidly growing community. It is an open-source high-performance drone radio communication platform that is focused on range and latency. ELRS ecosystems are available for 2.4GHz, 915 MHZ, or 868 MHz frequencies. BetaFPV ELRS product line allows an affordable way to experience this new technology. <br> Pros<br> +More Cost-effective than other radio systems;<br> +Open-source technology;<br> +Firmware upgradable solution;<br> +Multiple radio band options;<br> +Built-in telemetry system;<br> +Adjustable TX power;<br> <br> Cons<br> -New technology, not too much documentation<br>
